Custom PCB RF Shields EMI RFI Protection for High-Frequency Electronic Devices with Customized Precision Metal Stamping
Description Of Custom PCB RF Shields EMI RFI Protection for High-Frequency Electronic Devices with Customized Precision Metal Stamping
Custom PCB RF shields are specialized enclosures designed to mitigate electromagnetic interference (EMI) and radio-frequency interference (RFI) in high-frequency electronic circuits. These shields are fabricated using precision metal stamping, a manufacturing process that ensures high accuracy, repeatability, and cost-effectiveness for customized designs.
Material Of Custom PCB RF Shields EMI RFI Protection for High-Frequency Electronic Devices with Customized Precision Metal Stamping
Material and Testing Report | ||
Metal | Aluminum | Aluminum 2024 Aluminum 5052 Aluminum 6061-T6 |
Aluminum 6063 Aluminum 7075 Aluminum MIC 6 | ||
Stainlesss steel | SUS303, SUS304, SS316, SS316L | |
UNS S32304 UNS S32003 UNS S31803 UNS S32205 | ||
UNS S32760 UNS S32750 UNS S32550 UNS S32707 UNS S33207 | ||
Steel | 12L14 4140 1018 1045 12L14 4130 4142 ,O1 tool steel, | |
D2 tool steel,A36 1008 ,Alloy42 | ||
Titanium | Grades 1-4 Grade 5 Grade 9 | |
Brass | 260, C360, H59, H60, H62, H63, H65, H68, H70 | |
Copper | ||
Phosphor bronze | ||
Bronze | C932 | |
Carbon fiber | ||
PTFE | Polytetrafluoroethylene (PTFE) | |
Plastic | Acetal | (Polyoxymethylene (POM)) [Delrin] |
PEEK | Polycarbonate | |
Polystyrene | Polyether Ketone | |
Nylon | ||
ABS | ||
PVC | ||
Acrylic | ||
G-10 Garolite Fiberglass |
Finish Result | |
As Machined | Sharp edge and burrs will be removed |
Bead Blast | The part surface is left with a smooth, matte appearance |
Anodized | Type II creates a corrosion-resistant finish. Parts can be anodized in different colors—clear, black, red, and gold are most common—and is usually associated with aluminum. |
Type III is thicker and creates a wear-resistant layer in addition to the corrosion resistance | |
Powder Coat | This is a process where powdered paint is sprayed onto a part which is then baked in an oven. |
Customized | Cotact us via email, skype, whatsapp. We will look into a finishing process for you. |
Others | |
Tolerance | +/-0.005mm |
Lead Time | 1-2 weeks for samples, 3-4 weeks for mass production |
Drawing Accepted | Solid Works, Pro/Engineer, AutoCAD(DXF, DWG), PDF |
Payment Terms | TT/Paypal/WestUnion |
Industries Of Custom PCB RF Shields EMI RFI Protection for High-Frequency Electronic Devices with Customized Precision Metal Stamping
1. Aircraft parts
2. Automobile parts
3. Fixture parts
4. Medical parts
5. Petro chemical parts
6. Education parts
Features Of Custom PCB RF Shields EMI RFI Protection for High-Frequency Electronic Devices with Customized Precision Metal Stamping
1. High precision
2. Short processing time
3. Easier customized/personalized
Our Advantages
High Precision & Customization
Metal stamping allows for tight tolerances and complex geometries, enabling shields to fit precisely around irregular PCB layouts, connectors, and components.
Custom designs can incorporate venting, tabs, or slots for thermal management or signal passage without compromising shielding effectiveness.
Superior EMI/RFI Shielding Performance
Stamped metal shields provide excellent conductivity (e.g., steel, aluminum, or copper alloys) to reflect and absorb electromagnetic waves.
They create a Faraday cage effect, isolating noise-sensitive circuits from external interference and preventing internal emissions from affecting other devices.
Cost-Effective High-Volume Production
Metal stamping is a high-speed, low-waste process, making it ideal for large-scale manufacturing while maintaining consistency.
Unlike machined or cast shields, stamped parts have lower tooling costs and faster lead times for prototyping and production.
Durability & Reliability in Harsh Environments
Stamped shields are mechanically robust, resistant to vibration, shock, and temperature fluctuations.
They can be plated or coated (e.g., nickel, tin, or anodized finishes) for enhanced corrosion resistance and solderability during PCB assembly.
FAQ
Q1: Where can I get product & price information?
A1:Send us inquiry e-mail, we will contact you as we receive your mail.
Q2: How long can I get the sample?
A2:Depends on your specific items, within 3-7 days is required generally.
Q3: What kinds of information you need for quote?
A3:Kindly please provide the product drawing in PDF, and will be better you can provide in STEP or IGS.
Q4: What are the payment terms?
A4: We accept 50% as payment deposit, when the goods is done, we take photos for your check and you then pay the balance.
Q5: Are you a trading company or factory?
A5:We are direct factory with 10 experienced engineers and more than 650 employees as well approximate 2,000 square ft. workshop area.
Q6: What shall we do if we do not have drawings?
A6:Please send your sample to our factory, then we can copy or provide you better solutions. Please send us pictures or drafts with dimensions (Length, Hight, Width), CAD or 3D file will be made for you if placed order.
